Descriere
| Tip | Doza MM |
| Raport semnal zgomot (dB) | 1 |
| Culoare | Negru |
Ortofon – 100 ani de traditie daneza
Ortofon este liderul mondial in productia de ace si doze pentru pickup-uri, iar cifrele sunt in favoarea acestei afirmatii: compania implineste in 2018 o suta de ani de la infiintare, iar dozele Ortofon sunt compatibile cu peste 90% dintre pickup-urile existente pe piata.
| Output voltage at 1000 Hz, 5cm/sec. – 4 mV Channel balance at 1 kHz – 2 dB Channel separation at 1 kHz – 22 dB Channel separation at 15 kHz – 15 dB Frequency range at – 3dB – 20-25.000 Hz Frequency response – 20-20.000 Hz ± 2 dB Tracking ability at 315Hz at recommended tracking force *) – 65 µm Compliance, dynamic, lateral – 20 µm/mN Stylus type – Elliptical Stylus tip radius – r/R 8/18 µm Tracking force range – 1,5-2,0 g (15-20 mN) Tracking force, recommended – 1,75 g (17,5 mN) Tracking angle – 20° Internal impedance, DC resistance – 750 Ohm Internal inductance – 450 mH Recommended load resistance – 47 kOhm Recommended load capacitance – 200-600 pF Cartridge colour, body/stylus – Black/Black Cartridge weight – 5 g |
